Dual 3D light source

The perfect combination of 2D and 3D effectively eliminates the influence of shadows and provides high-quality 3D images with high-performance cameras, ensuring high precision and speed in testing.

64 bit Win 10 system
High speed and high stability computer system configuration to meet increasingly dense product designs.

Simple and clear user interface

The self-developed Gerber editor is easy to operate and program, with a single interface that can display all commonly used functions, avoiding the hassle of switching back and forth between multiple interfaces. The simple and clear interface is suitable for any level of operator operation.

True color 3D stereoscopic image

The usual SPI can only calculate the height above the silk screen, but Pemtron's patented ColorXY technology can easily distinguish copper foils and accurately find the zero reference plane. In addition, it can display true color 3D images rotated at any angle, making it easier for users to see clear and vivid solder paste images, thus avoiding the trouble of operators repeatedly confirming the actual object under the microscope.

High speed performance

By increasing the camera speed, the same testing speed as a single 3D projection can be achieved.

SPI Standard Component Library

Based on the experience of A0I component library, BenChuang took the lead in introducing SPI standard component library to standardize SPI parameters, that is, to achieve unified management of all program parameters.

When creating a new program, all pad parameters can be set by simply pressing the - key, reducing programming time.

Powerful SPC function

The SPC system can analyze defective data and production situations, making problems in the engineering production process clear at a glance.

SPC's data reports can be output in PDF, Excel, or Image formats, and users can save them in the desired format.

Automated detection data system

Printer Net - Closed loop system with printing machine

Mounter Net - Closed loop system with SMT machine - BadMark data sharing and automatic SMT optimization

APC - Utilizing SPI test data to automatically compensate for patch coordinates, thereby improving the quality of products after the furnace

PEMTRON SPI&AOI Closed Loop Functional-3 Point Control System

SMARTRON - One software can monitor up to 12 devices
